FI: 100 / HDG
LOG BANDSAW
Technical Specifications
| Flywheel Diameter | 1000mm (100cm (39.4 in)) |
|---|---|
| Flywheel Width | 120mm (12cm (4.7 in)) |
| Cutting Height | Max: 1200mm (120cm (47.2 in)) |
| Cutting Width | Max: 540mm (54cm (21.3 in)) |
| Main Motor | 30 kW / 40 hp / 1400 rpm |
| Hydraulic System Motor | 4 kW / 1400 rpm |
| Sawblade Tensioning | Hydraulic |
| Sawblade Guide Adjustment | Hydraulic |
| Weight | 2,800 kg (6,173 lb) |
| Upper & Lower Bearings | SKF C3 |
| Max sawblade Size | Max: 120 X 1.0 X 8150 mm (4.7 x 0.0 x 320.9 in) |
| Min Saw Blade Size Size | Min: 80 X 1.0 X 7900 mm (3.1 x 0.0 x 311.0 in) |
| Sawblade Lubrication Spray System | Automatic / Push Button |
| Electric Panel - StarDelta | Included – First class materials |
| Belt Drive Pulley System | Mounted on the machine |
| Machine Lubrication System | Manually Lubrication thru Grease Fittings |
| Body Structure | Steel construction |
| Machine Dimensions | 145 x 120 x 350 cm (57.1 x 47.2 x 137.8 in) (Length Width Height) |
| Daily Capacity (Log Cutting) | 30 m3 (≈12,714 bd ft) |
