LOG LOADING RAMP
– HYDRAULIC
– 4 m – 4 Legs
Technical Specifications
| Frame Type | 4 legs (4 rows of 180 NPI steel profile) |
|---|---|
| Log moved by | Chain Carrying |
| Log Loading | Hydraulic opening/closing bridges |
| Feed Rate | 30 m/min |
| Main Motor | 7.5 kW gear motor |
| Shipped as | Disassembled |
| Installation / Commissioning | On site Installation & Run |
| Approx. Weight | 2750 Kg (6,063 lb) |
| Machine Dimensions | 400 x 20 x 100 cm (157.5 x 7.9 x 39.4 in) (Length Width Height) |
