FI: 100 / HYM 3 HYDRAULIC HORIZONTAL MARKER – Triple
Technical Specifications
| Flywheel Diameter | 1000mm (100cm (39.4 in)) |
|---|---|
| Flywheel Width | 120mm (12cm (4.7 in)) |
| Working Width | 450mm (45cm (17.7 in)) |
| Cutting Height | Min: 15 mm (1.5 cm (0.6 in)) Max: 290 mm (29 cm (11.4 in)) |
| Saw Tensioner | Hydraulic |
| Cutting Height Adjustment | 4 Kw geared motor |
| Main Engine | (3 x40 hp) – 3 x 30 kW |
| Feed Rate | 2 to 60 m/min |
| Measurement System | Plc control color digital display |
| Flywheel Cleaning | Scraper System |
| Fueling System | Automatic timed / or manual |
| Upper Pressure Rollers and Drive System | Pneumatic- Motor with movable inverter |
| Machine Dimensions | 480 cm (189.0 in) x 365 cm (143.7 in). x 230cm (Length Width Height) |
| Weight | 9000 Kg (19,842 lb) |
