FI: 120 / HDG M HYDRAULIC VERTICAL BODY MARKOL
Technical Specifications
| Flywheel Diameter | 1200mm (120cm (47.2 in)) |
|---|---|
| Flywheel Width | 140mm (14cm (5.5 in)) |
| Maximum Cutting Width | 350mm (35cm (13.8 in)) |
| Maximum Working Width | 730mm (73cm (28.7 in)) |
| Minimum Cutting Height | 20mm (2cm (0.8 in)) |
| Maximum Cutting Width | 550mm (55cm (21.7 in)) |
| Feed Speed | 0 – 60 m/min. |
| Main Motor | 37 kW / 50 hp /1400 d |
| Sawblade Tensioning | Hydraulic |
| Sawblade Guide Adjustment | Hydraulic |
| Hydraulic Unit Power | 4+4 KW |
| Weight | 5800 kg (12,787 lb) |
| Positioning the Fence | PLC Control Panel. Color Touch Screen 18 Adjustable set sizes ready |
| Upper & Lower Bearings | SKF –C3 |
| Max Sawblade Size | 140 x 1.2 x 9350mm (5.5 x 0.0 x 368.1 in) |
| Min Sawblade Size | 140 x 1.2 x 8950mm (5.5 x 0.0 x 352.4 in) |
| Sawblade Lubrication Spray System | Automatic - timer adjustment |
| Electric Panel (Star Delta ) | Included. Siemens or Schneider , on the machine. |
| Belt Drive Pulley System | Mounted on the pulleys |
| Bearings Lubrication System | Manual, by hand grease pump |
| Machine Dimensions | 300 x 120 x 350 cm (118.1 x 47.2 x 137.8 in) (Length Width Height) |
| Hydraulic Cooling system | Automatic thermostat radiator fan system |
